Infrastructure

InHouse Facilities

CNC Plate Welding Machine

  • Working Size : 3300 mm x 2000 mm; 4000 mm x 4000 mm

    • CNC Pipe Welding Machine

  • Working Size : Length- 6000
  • Diameter - 100 mm to 250 mm

    • CNC Plasma Cutting Machine:

    Working Size 3500 mm x 1800 mm
    Wear Plate Cutting Thickness 20 mm
    M. S. Plate Cutting Thickness 100 mm

    hydraulic Press Machine:

    Working Width 2500 mm
    Wear Plate Bending Thickness 25 mm
    M. S. Plate Bending Thickness 25 mm

    Manual Plate Rolling Machine:

    Working Width 1850 mm
    Wear Plate Bending Thickness 20 mm
    M. S. Plate Bending Thickness 25 mm

    Rockwell Hardness Tester:

    Make SAROJ
    Model RAS
    Serial No. 11/2023-648
    Maximum Capacity 150 kgf
    Calibration Standard IS0 1586-2:2018
    IS 1586-2:2018

    Weighing Scale:

    Make Scale Tec
    Model SAB 323 CL
    Weight Range 0.000 to 300.000 gm

    Dry Sand Abrasion Tester:

    Make Micromatic Technologies
    Normal Load Up to 130 N Dead Weights and 4.87kg for ASTM G65 test.
    Disc Speed 200 rpm
    Wheel Diameter 228.7 x 12.7 mm
    Wheel Material Chlorobutyl rubber hardness: A 58 to 62 on Shore Durometer
    Revolution Up to 999999
    Abrasive Flow Rate 300 to 400 gm/min
    Sample Size 76.2 x 25.5 x 13 mm (variable)
    Sand Flow Rate
